Painted Wood Enclosures, Metal Grille, Rubber feet,
2 x Handles (Both Sides)
| Model | KPEX 8A | KPEX 10A | KPEX 12A |
|---|---|---|---|
| System Type | Active PA Speaker | Active PA Speaker | Active PA Speaker |
| Frequency response | 70Hz-19KHz | 58Hz-19KHz | 58Hz-19KHz |
| Amplification | LF: Class D + HF: Class AB | LF: Class D + HF: Class AB | LF: Class D + HF: Class AB |
| Bi-Amp Power (Continuous / Peak) | LF: 200W / 800W + HF: 50W / 200W | LF: 250W / 1000W + HF: 50W / 200W | LF: 450W / 1800W + HF: 50W / 200W |
| Power Total (Continuous / Peak) | 250W / 1000W | 300W / 1200W | 500W / 2000W |
| Max. SPL | 126dB | 130dB | 134dB |
| LF transducer | 8" Woofer, 2" Voice coil | 10" Woofer, 2" Voice coil | 12" Woofer, 2.36" Voice coil |
| HF transducer | 1" Exit, 1.35" Compression Driver | 1" Exit, 1.35" Compression Driver | 1" Exit, 1.35" Compression Driver |
| Dispersion | 90°x 60° | 90°x 60° | 90°x 60° |
| Crossover frequency | 2.6KHz | 2.5KHz | 2.8KHz |
| Connectors | Input: Combo XLR / TRS Balanced, Jack 3.5mm Bluetooth. Output: XLR | Input: Combo XLR / TRS Balanced, Jack 3.5mm Bluetooth. Output: XLR | Input: Combo XLR / TRS Balanced, Jack 3.5mm Bluetooth. Output: XLR |
| Dimension transportation | 365 x 345 x 510mm | 390 x 390 x 595mm | 460 x 450 x 695mm |
| Weight | 12.5kg | 15.8kg | 19.2kg |
| Net Weight | 13.6kg | 17.1kg | 20.9kg |
| Model | KPEX 15A | KPEX 215A MKII |
|---|---|---|
| System Type | Active PA Speaker | Active PA Speaker |
| Frequency response | 43Hz-19KHz | 40Hz-19KHz |
| Amplification | LF: Class D + HF: Class AB | LF: Class D + HF: Class AB |
| Bi-Amp Power (Continuous / Peak) | LF: 550W / 2200W + HF: 50W / 200W | LF: 750W / 3000W + HF: 50W / 200W |
| Power Total (Continuous / Peak) | 600W / 2400W | 800W / 3200W |
| Max. SPL | 136dB | 138dB |
| LF transducer | 15" Woofer, 3" Voice coil | 2 x 15" Woofer, 3" Voice coil |
| HF transducer | 1" Exit, 1.35" Compression Driver | 1" Exit, 1.35" Compression Driver |
| Dispersion | 90°x 60° | 90°x 60° |
| Crossover frequency | 2.5KHz | 2.5KHz |
| Connectors | Input: Combo XLR / TRS Balanced, Jack 3.5mm Bluetooth. Output: XLR | Input: Combo XLR / TRS Balanced, Jack 3.5mm Bluetooth. Output: XLR |
| Dimension transportation | 510 x 495 x 795mm | 570 x 520 x 1060mm |
| Weight | 23.6kg | 43kg |
| Net Weight | 25.7kg | 46.4kg |
| Model | KPEX18A SUB |
|---|---|
| System Type | Active PA Subwoofer |
| Frequency response | 30Hz-150Hz |
| Amplification | Class D |
| Power Total (Continuous / Peak) | 1200W / 3600W |
| Max. SPL (Peak) | 134dB |
| LF transducer | 18" Woofer, 4" Voice Coil |
| Cabinet Construction | 18mm Plywood |
| Cabinet Surface | Polyurea |
| Connectors | Input: XLR / Output: XLR |
| Dimension transportation | 800 x 655 x 815mm |
| Net Weight | 56.5kg |
| Features | Adjustable low-pass filter (80-150Hz) |
